MAXLE FRONT AXLES
MAXLE STEALTH
Who knew we could make a thru axle disappear? The new Maxle Stealth offers a light, low profile alternative to Maxle Lite and Maxle Ultimate.
34g lighter than Maxle Lite (Weight = 37g)
Easy installation with a 6mm Allen wrench|
SPECIFICATIONS
| Style |
Stealth |
| Lever Mechanism |
Tooled Axle |
| Hub Over Locknut Diameter |
15x100, 15x110, 15x150 |
| Axle Length / Thread Length |
15x 100(Road) - (125/9mm) 15 x 100 - (148/9mm), 15 x 110 - (158/10mm), 15 x 150 - (198/10mm) |
| Orientation |
Front |
| Thread Pitch |
M15 x 1.50 |
| Colour |
Black |
MAXLE ULTIMATE FRONT
Basic things like axles are often the easiest to overlook. Put one hand on the Maxle Ultimate, though, and you’ll be glad we paid serious attention to the finer details. Because one hand is all it takes to remove or install the Maxle Ultimate. And lever-placement personalization is accomplished completely without the use of tools. Available for both front and rear, Maxle Ultimate is the easiest-to-operate axle system in the world. No tools, no worries, so you can concentrate on the trail ahead.
Internal Cam system
High Clamping force
SPECIFICATIONS
| Style |
Ultimate |
| Lever Mechanism |
Internal Cam |
| Hub Over Locknut Diameter |
15 x 100 |
| Axle Length / Thread Length |
15 x 100 (148/9mm) |
| Orientation |
Front |
| Thread Pitch |
M15 x 1.5 |
| Colour |
Black |
|
|
MAXLE LITE FRONT 15mm & 20mm
The tool-free Maxle Lite brings exceptional stiffness and durability to your ride in the easiest-to-use through axle system on the market.
- Tool free operation
- 360 degrees head adjustment
SPECIFICATIONS
Style Lite
Lever Mechanism Expanding Wedges
Hub Over Locknut Daimeter 15 x 100, 15 X 150. 20 x 110
Axle length/Thread Length 15 x 100(148mm), 15 x 110(L158mm), 15 X 150(Bluto Compatible), 20x 110(165/9mm - 32mm Chassis), 20 x 110(165/9mm - 35/40mm Chassis)
Orientation Front
Thread pitch M15 x 1.5, M20 x 2
Color Black
MAXLE DH
Designed for the downhill crowd, this tooled version of our Maxle Lite is light and stiff and has loads of clearance
|
