Giant 2026 Reign Advanced E+ 0
Please contact store for availability on 04 589 2822 or support@cyclescience.co.nz
Giant 2026 Reign Advanced E+ 0
Frame
Size: S, M, L, XL
Colour: Purple Haze/Metallic Navy
Frame: Advanced-grade composite, Advanced Forged Composite Upper Rocker, 170mm Maestro suspension system, flip chip, UDH hanger 12x148mm thru-axle
Fork: Fox 38 Factory E-Tuned, 180mm travel, 44mm offset, GRIP X2 damper, Boost Kabolt-X 110x15mm
Shock: Fox Float X2 Factory, EVOL Large Volume sleeve, 2 position lever, custom tuned
Drivetrain
Crankset: Praxis Performance Carbon e-crank arms SRAM Eagle T-Type steel direct mount, 36T chain ring S:160mm, M: 160mm, L:160mm, XL:160mm
Pedals:
Chain: SRAM X0 T-Type
Bottom Bracket:
Rear Derailleur: SRAM XX Eagle T-Type AXS
Front Derailleur:
Derailleur Shifter: SRAM AXS Pod, Rocker Paddle, 1x12
Freewheel/Cassette: SRAM X0 XS-1295 Eagle T-Type 10-52T
Braking System
Brakes: SRAM Maven Ultimate, hydraulic, SRAM HS2 rotors [F]200mm, [R]200mm
Brake Levers: SRAM Maven Ultimate
Wheels
Tyres: Maxxis Assagai 29x2.5" foldable, Tubeless, EXO+, 3C MaxxGrip [F] Maxxis Minion DHR II 27.5x2.4" foldable, Tubeless, DoubleDown, 3C MaxxGrip Compound [R]
Wheels/Rims: Giant E-TRX Hookless Tubeless ready Carbon 29""[F] 27.5""[R] 30mm inner width
Hubs: Giant E-TRX MTB Alloy Hub, 6 Bolt, 110x15 [F] / 148x12 SRAM XD Drive Body Pawl Driver (6 Pawl 72T) Thru-axle [R]
Other
Handlebar: Giant Contact SLR Trail, integrated carbon 1-piece handlebar, 35mm Rize, 40/45/50mm Reach Adjust, +3/0/-3degree Angle Adjust System
Stem: Giant Contact SLR Trail, integrated carbon 1-piece handlebar, 35mm Rize, 40/45/50mm Reach Adjust, +3/0/-3degree Angle Adjust System
Seat Post: Fox Transfer Factory dropper, remote S: 150mm travel / 30.9 x 411mm M:180mm travel / 30.9 x 476mm L: 210mm travel / 30.9 x 551mm XL: 210mm travel / 30.
Saddle: Giant Romero SL
E-Bike
Drive Unit: Giant SyncDrive Pro 3, 48v, 90Nm, powered by Yamaha
Battery: Giant EnergyPak Smart 560Wh, integrated, 48V, Giant EnergyPak Plus 280 range extender
Controller: RideControl Ergo 4, grip integrated
Display: RideControl GO LUX, frame integrated LED display ANT+
Charger: EnergyPak 4A smart charger
Giant 2026 Reign Advanced E+ 0
| S | M | L | XL | |
|---|---|---|---|---|
| LOW | MID | HIGH | LOW | MID | HIGH | LOW | MID | HIGH | LOW | MID | HIGH | |
| A Seat Tube Length (mm) | 400 | 425 | 450 | 475 |
| A1 Seat Post Insertion Depth (mm) | 235 | 260 | 285 | 310 |
| B Seat Tube Angle | 77.1° | 77.5° | 77.9° | 77.1° | 77.5° | 77.9° | 77.1° | 77.5° | 77.9° | 77.1° | 77.5° | 77.9° |
| C Top Tube Length (mm) | 570 | 569 | 568 | 602 | 601 | 600 | 625 | 624 | 623 | 657 | 656 | 655 |
| D Head Tube Length (mm) | 95 | 105 | 120 | 135 |
| E Head Tube Angle | 63.1° | 63.5° | 63.9° | 63.1° | 63.5° | 63.9° | 63.1° | 63.5° | 63.9° | 63.1° | 63.5° | 63.9° |
| F Fork Rake (mm) | 44 | 44 | 44 | 44 |
| G Trail (mm) | 133.3 | 130.3 | 127.4 | 133.3 | 130.3 | 127.4 | 133.3 | 130.3 | 127.4 | 133.3 | 130.3 | 127.4 |
| H Wheelbase (mm) | 1226 | 1226 | 1227 | 1261 | 1261 | 1261 | 1287 | 1288 | 1288 | 1323 | 1323 | 1324 |
| I Chain Stay Length (mm) | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 | 450 |
| J Bottom Bracket Drop (mm) | 10 | 5 | 10 | 5 | 10 | 5 | 10 | 5 |
| K Stack (mm) | 647 | 645 | 642 | 656 | 654 | 651 | 669 | 667 | 665 | 683 | 680 | 678 |
| L Reach (mm) | 426 | 430 | 435 | 456 | 460 | 465 | 476 | 480 | 485 | 505 | 510 | 514 |
| O Stem Length (mm) | 40 | 40 | 40 | 40 |
| P Crank Length (mm) | 160 | 160 | 160 | 160 |
| Q Wheel Size | R27.5" / F29" | R27.5" / F29" | R27.5" / F29" | R27.5" / F29" |
*Please note that our specifications may be impacted by running substitution changes, we highly recommend confirming the specifications of our products at the time of sale. *Recommended Retail Prices are subject to change without notice and may vary from store to store depending on freighting and assembly costs. Please read our Terms & Conditions
*Giant & Liv Bicycles are available for purchase online, but due to warranty regulations, must be shipped to qualified Giant dealers, as bicycles must be assembled by a qualified bike mechanic in an approved store - This is an international policy and usually will require an additional fee to build the bike. This will be confirmed by one of our online staff after purchase of the bike.
